THERMOFORMING: CMS MADE IT EASIER!
Simple management of all process parameters thanks to a userfriendly software specifically developed for thermoforming process.
It shortens by 53% learning times compared to different solutions using wizard procedures. All variables are saved in a single program ensuring the same results even after years.
THE UNIQUE * SOLUTION FOR HEATING MANAGEMENT THAT ONLY CMS CAN OFFER (*PATENTED)
Smart heating control advanced system using thermal vision thanks to the exclusive ThermoProphet by CMS. Thermal image allows to read surface temperature and through this information apply modifications to heating percentages automatically. This allow to ensure maximum heating quality even with every kind of environmental conditions. Thanks to this is possible to reduce probability of bad parts by 55% end restart time by 25%
BE UNDER PRESSURE: QUALITY ASSURANCE
Possibility to work with both vacuum and pressure forming. By using pressure from upper table (with counter mould or pressure bell) is possible to obtain an excellent details definition with the possibility to have texture transfer from the mould. Through pressure forming is possible to guarantee perfect forming of extreme undercuts and excellent results also with thermoplastic composite materials.
LOADING/UNLOADING: IT HAS NEVER BEEN SO EASY AND CONFORTABLE
Fully automatic sheet loading system with alignment and centering of a single sheet. During centering cycle plates are raised slightly to reduce the probability of scratching shiny surfaces. A laser system is able to detect double sheet situation and thanks to separation function is able to ensure that only one plate will be loaded at a time. Loading and unloading operations will be easier and safer.
